Description：
The DAAOBX-8 is a portable air-pressurized emergency eye/face wash station designed for industrial locations where a permanent water supply is unavailable or difficult to install.
The unit uses a stainless steel pressurized tank to provide an independent emergency flushing water source without requiring connection to a fixed water system. After filling the tank with clean water and charging it with compressed air, the system can be quickly deployed to temporary workplaces, remote sites, and maintenance areas.
The integrated eye/face wash provides ≥11.4 L/min flushing flow, while the flexible body spray hose extends flushing coverage for additional localized body rinsing applications.
Constructed from AISI 304 stainless steel with AISI 316L available as an option, the DAAOBX-8 provides corrosion resistance and durability for demanding industrial environments.
01 — Independent Pressurized Water Supply
The air-pressurized stainless steel tank provides emergency flushing water without requiring a fixed water connection.
02 — Portable Eye/Face Wash Design
Provides emergency eye and face flushing capability in a compact mobile configuration for temporary and remote work areas.
03 — Stainless Steel Pressure Tank
AISI 304 stainless steel construction with optional AISI 316L provides corrosion resistance and durability for industrial environments.
04 — Extended Flushing Coverage
The integrated flexible body spray hose expands flushing capability for localized body exposure and emergency rinsing applications.
05 — Pressure Safety Protection
Equipped with a pressure gauge and safety relief valve to monitor internal pressure and ensure safe operation.
06 — Easy Refill & Recharge
The tank can be refilled with clean water and repressurized with compressed air for repeated deployment.
Applications
Chemical，Mining & Remote Industrial Sites，Oil & Gas Facilities，Construction & Temporary Work Areas，Manufacturing & Maintenance Areas，Laboratories & Testing Facilities
Operating Procedure
Step 1 — Fill the Tank with Water
Fill the stainless steel tank with clean flushing water according to the marked water level indication to ensure proper operating capacity.
Step 2 — Pressurize the Tank
Charge the tank with compressed air until the internal pressure reaches the specified working pressure (approximately 0.3 MPa).
The built-in pressure gauge allows monitoring of tank pressure. A preset safety valve automatically releases excess pressure if the internal pressure exceeds the safety limit.
Step 3 — Deploy and Operate
Move the unit to the required working location. The system is ready for emergency use:
Push the eyewash activation plate for eye/face flushing.
Pull the shower handle for full-body flushing.
Step 4 — Refill and Recharge
When the water capacity is depleted, release the remaining air pressure, refill the tank with clean water, and recharge the system with compressed air for continued operation.
